Make sure that the installation xes synergix 8825 near the socket outlet and is easily accessible. Do not allow anything to rest on the power cord. Do not locate the printer where someone will step on the cord. To ensure reliable operation of the printer and to protect it from overheating, never position the printer so that these openings are near a radiator or heat register. Xes synergix 8825 printer should not be placed in a built-in installation unless adequate ventilation is provided. Never push objects of any kind into the slots of the printer in order to avoid touching dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the printer.

Never remove any covers or guards that require a tool for removal.

Dieterich-Post Main Page

There are no operator serviceable areas within these covers. Never attempt any maintenance function that is not specified in this operator manual. Never defeat the interlock switches. Your printer is designed to prevent operator access to xes synergix 8825 areas.

XES Synergix 8825/8830/8850/8855 & X2-TECH System

The covers, the guards, and the interlock switches xes synergix 8825 provided to ensure that the system will not operate when the covers are open. Unplug the printer from the wall outlet and refer all servicing to qualified service personnel under the following conditions: When xes synergix 8825 power cord is damaged or frayed. If liquid has been spilled into the printer. If the printer has been exposed to rain or water. If the printer is producing unusual noises or odors. If the printer or the cabinet has been damaged. This safety device will remove all power to the printer if an electrical fault is detected by the GFI.

In the event xes synergix 8825 power is interrupted to the printer, locate the GFI safety device located on the right side of the printer next to the power cord: Check that a red indicator appears in the window A of the safety device as shown opposite. The red indicator should appear in the window, and power should be restored to the printer. If the device interrupts power to the printer again, or if power is not restored by performing the above procedure, call Xerox Service to correct the problem. Control Panel Make keypad entries and read the printer status and messages here.

Drawer 1 Top Open to load paper rolls and to clear media jams. Drawer 2 Middle Open to load paper rolls and to clear media jams. Optional on the Drawer 3 Bottom Open to load paper rolls and to clear media jams. Not available on the Lower the cover to remove jammed media. Front Door Provides an access to the waste toner bottle. Cutter Drawer Open to clear media jams in the cutter. Power Cord Connection Connect the power cord here and xes synergix 8825 a suitable outlet. Product Roadmap Refer to Table 1 to determine the installation procedure. Go to the installation by clicking on the Procedure number in the left column or in the case of a paper copy, go to the procedure with that name, later in this guide.


Check space and power against requirements. Install printer. Note: When installing firmware 8. Dark The Background Suppression option enables you to make adjustments for documents xes synergix 8825 contain poor contrast between the foreground image and the background. The Background Suppression selections work with the Dynamic Image Quality Dynamic IQ feature, that pre-scans the image, to ensure the best image quality possible. Getting to know the Synergix Digital Solution continued Preset Preset factory default allows xes synergix 8825 to select a predefined reduction or enlargement percentage. To select the Preset mode: 1.

Xerox XES Synergix Manuals

The illustration below depicts the middle portion of the Control Panel. It consists of up to four lines of text and graphics. The display can be adjusted upward for better viewing.


In the SCAN mode, the scanned image, or set of images, is stored on the xes synergix 8825 disk for later retrieval over a network by a client running on a remotely located device. To the left of some of the keys are indicator lamps that illuminate when the associated feature has been selected. An indicator lamp adjacent to each feature key illuminates whenever the corresponding feature is activated. The Printer and the Controller For information about the Printer and Controller components of the Synergix Digital Solution and about network connectivity, refer to the documentation listed below.

Wait for 30 seconds or until a P is displayed on the status LED.Xerox XES Synergix Pdf User Manuals. View online or download Xerox XES Synergix System Introduction, Operator's Xes synergix 8825.

XEROX®,XES Synergix Digital Solution,XES Synergix. Digital Solution,XES Synergix Digital Solution, Synergix.
